Domain walls on TGS

PFM, SCM and C-AFM maps of TGS crystal. Scanning Capacitance Microscopy of Triglycine Sulfate Crystals with the Profile Chromium Distribution Doi: 10.1134/S1063774518050115
Device: NTEGRA Aura
Sample Courtesy: Dr. Radmir Gainutdinov
Image Courtesy: Dr. Radmir Gainutdinov

dcdz_100x100um
dcdz_100x100um
Domain walls on TGS

size: 100x100 um
SPM principle: Piezoresponse Force Microscopy
100x100umcurrent
C-AFM

size: 100x100 um
TGS domain structure
Sapphire monocrystal irradiated by high energy Bi ions
