Microchannel plate

AFM image of the microchannel plate's (MCP) cell matrix. Every dark circle is a pore, which operates as a electron-multiplier tube if 1kV is applied. Diameter of each pore is 10 um and the distance from one center to the next center is 12 um. MCP is produced from leaden-silicate glass and MCP is used as electron-volume amplifier.

Image courtesy of V. A. Smirnov, Taganrog State University Of Radioengineering College of Electronics and Electronic Equipment Engineering.


zast_mcp_300
zast_mcp_300
Microchannel plate


size: 50x50x1.7 um
SPM principle: Atomic Force Microscopy
zast_mcp_300a
Microchannel plate


size: 50x50x1.7 um
SPM principle: Atomic Force Microscopy
