YIG domains reorganization

MDT-file: Download

The MFM images of the magnetic domain structure of Yttrium Iron Garnet film before (upper) and after (lower) a magnetic field was applied in X-direction.
Magnetic images are obtained with SOLVER MFM

Image courtesy of, S. Nesterov, NT-MDT, Moscow, Russia.


yig_domains_reorganization_300
yig_domains_reorganization_300
YIG domains reorganization
MFM image before a magnetic field was applied in X-direction.
size: 31x31 um
SPM principle: AC MFM
yig_domains_reorganization_300a
YIG domains reorganization
MFM image a magnetic field was applied in X-direction.
size: 31x31 um
SPM principle: AC MFM
