RSI_SRI. CNT on SiO2 sample

Carbon nanotubes on SiO2. BV applied to sample. RSI + SRI scan. Seems that on Current Image we can distinguish 2 separate nanotubes (horizontal tube). On corresponding Stiffness Image we see that this tube is softer.
Device: NTEGRA Prima
Tip: NSG01/Pt
Sample Courtesy: Sample courtesy: Dr. Kuljanishvili’s lab at Saint Louis University, Department of Physics
Image Courtesy: Stanislav Leesment, Sergey Zayats

topo_shad__2_curr_over_1
topo_shad__2_curr_over_1
RSI_SRI. CNT on SiO2 sample

size: 1x1 um
SPM principle: HD
stiff_curr_over_4
Current over Stiffness overlay

size: 1x1 um
SPM principle: HD
topo_shad__2_curr_over
Current over Topography overlay

size: 1x1 um
SPM principle: HD
current_2
Current

size: 1x1 um
SPM principle: HD
stiff_1
Stiffness

size: 1x1 um
SPM principle: HD
topo3d_3
Topography

size: 1x1 um
SPM principle: HD
