Archived Webinars

Dr. Sergei Magonov

High Resolution Imaging in Different AFM Modes

NT-MDT are delighted to invite you to attend a webinar on Tuesday November 11 at 11am (MST) presented
by Dr. Sergei Magonov on High Resolution Imaging in Different AFM Modes.

High-resolution imaging is a primary function of Atomic Force Microscopy (AFM), and the related applications are continuously expanding with the ongoing instrumental developments. An operation at small scales (<100 nm) has a number of factors that influence the signal-to-noise ratio and spatial resolution of the images. They include a precise force control, especially, in the low-force regime, tip dimensions, and operation in low thermal drift environment. Furthermore, the imaging media and nature of the sample are also very essential for the success of the experiments at the atomic- and molecular-scale. The progress in the high-resolution achieved in studies in ultra-stable thermal environment is the subject of this Webinar. The following key results will be presented:

·   An operation of AFM microscope in a temperature-stable cabinet facilitates high-resolution studies and makes molecular-scale imaging of different materials a routine procedure.

·   The imaging at the atomic and molecular scale is achieved on a number of samples not only in contact mode but also in the oscillatory resonant (Amplitude Modulation) and non-resonant (HybriD) modes.

·    The tip-sample force interactions, which are different in the various AFM modes, help to visualize diverse types of adsorbate structures with the weakly-bonded adsorbates seen only in the oscillatory resonant mode.

Dr. Stanislav I. Leesment

Basic Principles of AFM Advanced Modes & Applications

The webinar took place on July 16, 2014.

Presentation of webinar  (7.2 Mb)

Please click here to view recording of the webinar

The webinar cover the following topics:

·         Physical principles of Atomic Force Microscopy  –  contact and noncontact/semicontact modes, Phase, Amplitude (Feedback Error)

·         Choice of the cantilever

·         High resolution

·         Spreading resistance imaging (Conductive AFM/Current mapping)

·         Kelvin Probe Microscopy (KPM), single and double pass

·         Piezoresponse Force Microscopy (PFM)

·         Magnetic Force Microscopy (MFM)

·         Nanolithography mechanical and electrical, Vector and Raster

·         HybriD™ Mode, the future of the Atomic Force Microscopy.

This should help in terms of getting the results you require from your application of AFM within research parameters and help to crystallise some of the principles that are being taught within your institutions.

Dr. Sergei Magonov

TITANIUM - the revolutionary step in AFM design

It’s time for an AFM cantilever Revolution! NT-MDT - Your AFM & Raman Company invites you to join our upcoming webinar about the TITANIUM Atomic Force Microscope and be first to learn about this revolutionary step in AFM design – Multiprobe Cartridge.

Our presenter will be Dr. Sergei Magonov.

Dr. Magonov received a doctorate in physics and mathematics from the Moscow Institute of Physics and Technology. Sergei has published over 200 peer-reviewed papers, 1 book, and 15 book chapters. He is now CEO of NT-MDT Development, an R&D subsidiary that was established for the development of novel experimental and applications capabilities using NT-MDT microscopes.

Who should attend? Materials Scientists, Physicists, Engineers, and Chemists interested in:

  • Breakthrough low thermal drift
  • High resolution imaging
  • Multiprobe AFM cantilevers
  • Automated AFM measurements
  • Advanced imaging techniques (HybriD, multi-frequency…)

AFM imaging with the Multiprobe Cartridge has been successfully applied in variety of applications. AFM usability has been enhanced to users of all skill levels. The revolutionary development in Atomic Force Microscopy – Multi-probe Cartridge - will be presented to show its advantages for the streamlined usability of TITANIUM AFM.

Recent achievements in high resolution imaging will be presented by examples obtained on different samples (polymers, composites, biomaterials, metals, semiconductors). The presented results were obtained in variety of modes (Amplitude Modulation, HybriD, single-pass Kelvin Force Microscopy, etc) with the use of different multi-frequency approaches. The essential issues of such studies related to spatial resolution, system noise and drift performance requirements will be discussed.
